Thread: Wiring diagram for kenwood kna-dv4100 |

New member Username: Cemenem
Post Number: 1
Registered: Oct-06
|
| Posted on Monday, October 16, 2006 - 10:53 am: |
|
hey guys i lost the wiring diagram for kenwood kna-dv4100 so i dont know where all these
cables goes i am getting crazy i need help pls.
IT IS KENWOOD KNA-DV4100 navigation, thanks |
|
Relevant Product Info
|
|
Gold Member Username: Tjmutlow
Post Number: 3017
Registered: Sep-05
|
| Posted on Monday, October 16, 2006 - 09:40 pm: |
|
go to kenwoods site |
New member Username: Cemenem
Post Number: 2
Registered: Oct-06
|
| Posted on Monday, October 16, 2006 - 10:16 pm: |
|
i went to kenwood site nothing, i could not find it, i have been searching for 2 weeks already, i lost the wiring diagram, it was on a peper, show which cable goes where, i am sure someone out there has the same unit, i know white goes to speed, green parking brake, and pink goes to back up light. but 5 other cable left, one for illumination, other to speaker. |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 329
Registered: Jul-06
|
| Posted on Wednesday, October 18, 2006 - 04:24 pm: |
|
Kenwood Kna-DV4100
wiring :
Black----Ground wire,to car chassis
Yellow---Battery wire 12V
Red------Igninition wire 12V
Orange---Automatic illumination control wire
Brown----TEL Mute wire
Pink-----Reverse detection Wire
White----To the car speed signal harness
Green----Parking sensor wire
PS.Att.Do not cut off the holder marked "S SENS" it's containing a protection diode.Doing so will cause a fault with the car! |
New member Username: Cemenem
Post Number: 3
Registered: Oct-06
|
| Posted on Wednesday, October 18, 2006 - 08:05 pm: |
|
thank you very much jenifer you are great help. |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 331
Registered: Jul-06
|
| Posted on Wednesday, October 18, 2006 - 10:11 pm: |
|
de nada, any time! Cemenem! |
New member Username: Cemenem
ACWORTH,
GEORGIA
USA
Post Number: 4
Registered: Oct-06
|
| Posted on Wednesday, October 18, 2006 - 11:33 pm: |
|
hey jeny looks like u know about these stuf, if you do not mind i need help, i am planing to install my navigation to my 2001 infiniti qx4, i have already installed the head unit, now it is time to install the nav, rear view camera and sub, camera and sub is easy, but nav, where do i connect speed wire; last time when i installed it to my 3 series bmw, i connected to the a cable in speedometer. i think speed wire goes in similar place or somewhere in trany. thank you mucho cemfbny@yahoo.com |
New member Username: Cemenem
ACWORTH,
GEORGIA
USA
Post Number: 5
Registered: Oct-06
|
| Posted on Wednesday, October 18, 2006 - 11:33 pm: |
|
hey jennifer, hola, looks like u know about these stuf, if you do not mind i need help, i am planing to install my navigation to my 2001 infiniti qx4, i have already installed the head unit, now it is time to install the nav, rear view camera and sub, camera and sub is easy, but nav, where do i connect speed wire; last time when i installed it to my 3 series bmw, i connected to the a cable in speedometer. i think speed wire goes in similar place or somewhere in trany. thank you mucho cemfbny@yahoo.com |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 347
Registered: Jul-06
|
| Posted on Thursday, October 19, 2006 - 03:11 pm: |
|
Hola Cemenem !Ok here we are,both wires run to speedometer but I think you have to try Green/Yellow ,If not then connect to Light Blue
 |
|
|
New member Username: Cemenem
ACWORTH,
GEORGIA
USA
Post Number: 6
Registered: Oct-06
|
| Posted on Thursday, October 19, 2006 - 03:38 pm: |
|
muchos gracias jenny , i have just finished installing nav, but i did not connect the speed wire, i have just seen your message, i will try as soon as i get a time, everything else works perfect, thanks alot again, by the way de donde eres? |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 348
Registered: Jul-06
|
| Posted on Thursday, October 19, 2006 - 04:07 pm: |
|
Colombia, Bogota! |
New member Username: Cemenem
ACWORTH,
GEORGIA
USA
Post Number: 7
Registered: Oct-06
|
| Posted on Thursday, October 19, 2006 - 05:16 pm: |
|
hey jenny ,as i have seen till now the most beautiful girls from colombia, ands i am sure your are as well, can we chat sometimes here is my e-mail adress cemfbny@yahoo.com yes by the way i am handsome turk, and my name is cem |
New member Username: Cemenem
ACWORTH,
GEORGIA
USA
Post Number: 8
Registered: Oct-06
|
| Posted on Thursday, October 19, 2006 - 07:20 pm: |
|
hey jenny thank you so much, u help me so far now i am on the way connecting speed wire, on the diagram u sent, it says green/yellow. is it green with yellow stripes, or greenish yellow color, thanks again |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 349
Registered: Jul-06
|
| Posted on Thursday, October 19, 2006 - 09:46 pm: |
|
about chit chat:
sorry Cem,next month i am going to marry!
about the wire :it's
green with yellow stripes. |
New member Username: Cemenem
ACWORTH,
GEORGIA
USA
Post Number: 9
Registered: Oct-06
|
| Posted on Thursday, October 19, 2006 - 10:09 pm: |
|
that is fine, i am getting merry next month as well, i was tring to be friend only, but that's ok then, thank you very much for your help, i tried 3 cables then finally found it, i could not find it without your help. i wish you all the best on your wedding, wish you heppines together with your future husband. |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 350
Registered: Jul-06
|
| Posted on Thursday, October 19, 2006 - 10:46 pm: |
|
Thanks Cem for the warm words!
BTW.I loved TURCIA, ANTALIA !Twice I been there...nice...wow and arabic markets it's something!!!
Yala Good Luck ! |
Silver Member Username: Delsole
Post Number: 946
Registered: Feb-05
|
| Posted on Friday, October 20, 2006 - 04:28 pm: |
|
big pimpin
haha |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 366
Registered: Jul-06
|
| Posted on Friday, October 20, 2006 - 04:38 pm: |
|
We doin' big pimpin, we spendin' cheese (Check 'em out now )
Big pimpin'
On B.L.A.P.'s
We doin' big pimpin' up in NYC
It's just that Jigga-man, Pimp-C and B.U.N.B.
Check em out now
------------
You know Joseph Kubiak I thug 'em, fu*ck 'em, love 'em, leave 'em
Cause I don't fu*ckin' need 'em
Take 'em out the hood
Keep 'em looking good
But I don't fu*ckin' feed em
First time they fuss I'm breezin'
Talking 'bout what's the reasons
I'm a pimp in every sense of the word, bi*tch
Better trust and believe 'em
In a cut where I keep 'em
'Til I need a nut
'Til I need to be (in) the guts
The it's beep-beep and I'm pickin 'em up
Let 'em play with the dick in the truck
Many chicks wanna put Jigga fist incuffs
Divorce him and split his bucks
Just because you got good head
I'mma break bread
So you can be livin' it up
Sh*it I part's wit nothin
Y'all be frontin'
Me give my heart to a man
Not for nothin' never happen'
I'll be forever mackin'
Heart cold as as*sas*sins, I got no passion
I got no patience and I hate waitin'
Hoe get your a*ss in
nice song! |
New member Username: Noskahn
CA
Post Number: 1
Registered: Jan-07
|
| Posted on Wednesday, January 31, 2007 - 03:00 am: |
|
Jenifer
Your the best! I had the same issue, lost thoes silly instructions. UGH!
Stupid PKG was showing up enabled.
Not sure if it will effect anything, but it was bugging me :-)
Thanx a million
-Leo |
