Thread: Wiring help new thread |

Gold Member Username: Tjmutlow
Post Number: 2125
Registered: Sep-05
|
| Posted on Sunday, May 28, 2006 - 04:16 pm: |
|
post here, to much in other threads |
|
|
|
New member Username: Combo65
Post Number: 3
Registered: May-06
|
| Posted on Monday, May 29, 2006 - 03:48 pm: |
|
I need stereo color codes for 2006 Ford ranger. |
New member Username: Essadis911
Calgary,
Alberta
Canada
Post Number: 3
Registered: May-06
|
| Posted on Monday, May 29, 2006 - 11:29 pm: |
|
can anyone help me i posted one in the other thread and mabe get something here to i need stereo wire color for a 1992 chevy S10 Blazer
|
New member Username: Jonthegr8tone1
Dsm,
Ia
Us
Post Number: 4
Registered: May-06
|
| Posted on Tuesday, May 30, 2006 - 12:48 am: |
|
i need stereo color codes for a 98 ply neon |
New member Username: Fank7878
Woodsfiled,
Oh
Usa
Post Number: 1
Registered: May-06
|
| Posted on Tuesday, May 30, 2006 - 12:59 am: |
|
yea i need a wiring diagaram for the hed unit of a 2000 f150 want to put new cd plaer but need the code for the wiring so if i culd get a pic or at lest the code id be happy in need of some help |
Silver Member Username: Thomas_g
NM
Post Number: 820
Registered: Oct-05
|
| Posted on Tuesday, May 30, 2006 - 02:40 am: |
|
lol ty finally!! jk, i figured sum 1 would finally start a new 1. |
New member Username: Fank7878
Woodsfiled,
Oh
Usa
Post Number: 2
Registered: May-06
|
| Posted on Tuesday, May 30, 2006 - 12:49 pm: |
|
so does any one have the coler code
|
Gold Member Username: Tjmutlow
Post Number: 2136
Registered: Sep-05
|
| Posted on Tuesday, May 30, 2006 - 12:56 pm: |
|
1990-94 Chevrolet Blazer S-Series Stereo Information
Constant 12V+ Orange
Switched 12V+ Yellow
Ground Black
Illumination Gray
Dimmer Brown
Antenna Trigger Pink
Antenna Right Front
Front Speakers 4" x 6" Dash
Left Front (+) Tan
Left Front (-) Gray
Right Front (+) Light Green
Right Front (-) Dark Green
Rear Speakers 6" x 9" Side Panels
Left Rear (+) Brown
Left Rear (-) Yellow
Right Rear (+) Dark Blue
Right Rear (-) Light Blue
• Alarm Information • Cruise Information
1990-94 Chevrolet Blazer S-Series Stereo Information
Constant 12V+ Orange
Switched 12V+ Yellow
Ground Black
Illumination Gray
Dimmer Brown
Antenna Trigger Pink
Antenna Right Front
Front Speakers 4" x 6" Dash
Left Front (+) Tan
Left Front (-) Gray
Right Front (+) Light Green
Right Front (-) Dark Green
Rear Speakers 6 1/2" Rear Doors
Left Rear (+) Brown
Left Rear (-) Yellow
Right Rear (+) Dark Blue
Right Rear (-) Light Blue
• Alarm Information • Cruise Information
|
Gold Member Username: Tjmutlow
Post Number: 2137
Registered: Sep-05
|
| Posted on Tuesday, May 30, 2006 - 12:57 pm: |
|
1998 Dodge Neon Stereo Information
Constant 12V+ Pink
Switched 12V+ Red/White
Ground Black
Illumination Orange
Dimmer Black/Yellow
Antenna Right Front
Front Speakers 6 1/2" Doors
Left Front (+) Dark Green
Left Front (-) Brown/Red
Right Front (+) Purple
Right Front (-) Dark Blue/Red
Rear Speakers 6" x 9" Rear Deck
Left Rear (+) Brown/Yellow
Left Rear (-) Brown/Light Blue
Right Rear (+) Dark Blue/White
Right Rear (-) Dark Blue/Orange
|
Gold Member Username: Tjmutlow
Post Number: 2138
Registered: Sep-05
|
| Posted on Tuesday, May 30, 2006 - 12:58 pm: |
|
2000 Ford F Series Stereo Information
Constant 12V+ Light Green/Pink
Switched 12V+ Black/Purple
Ground Black/Green
Illumination Light Blue/Red
Dimmer n/a
Amplifier Remote Blue
Antenna Right Front
Front Speakers 6" x 8" Doors
Left Front (+) Gray/Light Blue
Left Front (-) Tan/Yellow
Right Front (+) White/Light Green
Right Front (-) Dark Green/Orange
Rear Speakers 6" x 8" Rear Corners
Left Rear (+) Orange/Light Green
Left Rear (-) Light Blue/White
Right Rear (+) Orange/Red
Right Rear (-) Brown/Pink
• Alarm Information • Cruise Information
|
New member Username: Ryanuk
Post Number: 2
Registered: May-06
|
| Posted on Tuesday, May 30, 2006 - 02:38 pm: |
|
Can somone give me the wiring colours for my 1998 Ford Escort Finess 1.6
I looked at somone who posted one for a escort 1998 but its not the same as mine mine has orange and black wries can anyone help? |
New member Username: Bobimpact
Post Number: 1
Registered: May-06
|
| Posted on Tuesday, May 30, 2006 - 04:22 pm: |
|
2006 Ford Ranger
Radio 12v: lt. green/purple
Radio Ground: black and black/lt. Green
Radio Ignition: black/pink
Radio Illumination: lt. blue/red (dimmer)
Factory Amp Turn-on white/purple or purple/lt blue
Power Antenna N/A
LF Speaker +/- orange/lt. grn - lt. blue/wht +,- radio harness or amplifier
RF Speaker +/- white/lt. grn - dk. green/org +,- radio harness or amplifier
LR Speaker +/- gray/lt. blue - tan/yellow +,- radio harness or amplifier
RR Speaker +/- orange/red - brown/pink +,- radio harness or amplifier
|
New member Username: Buddha
Post Number: 1
Registered: Jun-06
|
| Posted on Saturday, June 24, 2006 - 11:34 am: |
|
i need wiring information on 2006 Ford F150 xlt |
Gold Member Username: Drivingreckless
Near tampa,
Florida
United state...
Post Number: 1171
Registered: Apr-06
|
| Posted on Monday, June 26, 2006 - 09:45 am: |
|
i need wiring info for a 2005 dodge charger |
Gold Member Username: Drivingreckless
Near tampa,
Florida
United state...
Post Number: 1173
Registered: Apr-06
|
| Posted on Monday, June 26, 2006 - 09:59 am: |
|
^^^^^for stock HU |
New member Username: Blah_blah
Post Number: 2
Registered: Jun-06
|
| Posted on Friday, June 30, 2006 - 09:53 pm: |
|
99 escort zx2 w/ premium sound (not sure if it matters) |
New member Username: Bradzbrad
Abbotsford,
B.c
Canada
Post Number: 3
Registered: Jun-06
|
| Posted on Sunday, July 02, 2006 - 10:14 am: |
|
--------------------------------------------------------------------------------
I posted a new thread then i saw this one ! I`m sorry if this is considered dbl posting but i need the wiring info for a 96` olds factory am fm cd cassette unit. I hope someone(= TY) can help. thanks : ) |
New member Username: Twizled
Fort Worth,
TX
USA
Post Number: 2
Registered: Jul-06
|
| Posted on Monday, July 03, 2006 - 10:22 pm: |
|
Need 2001 Mitsubishi Eclipse Stereo Information!!?? |
New member Username: Red_seal
Post Number: 3
Registered: Jul-06
|
| Posted on Tuesday, July 04, 2006 - 12:26 am: |
|
I am looking for the color code on the wiring harness for the 2002 Ford F-150 Supercab. I need to find out which wires are the speakers wires and which is which and the remote wire...I have an output converter so I can take the signal from the back of factory stereo and convert it to RCA to send to my amp. Is that the best way to go?
Thanks |
New member Username: Rodak
Post Number: 1
Registered: Jul-06
|
| Posted on Tuesday, July 04, 2006 - 12:31 pm: |
|
1998 Dodge Caravan:
I need the pinout info, not the wire colors. I have the head unit, not the wiring harness, and need to bench test it to verify that it works before selling it. |
New member Username: Acalder
Richardson,
TX
Post Number: 2
Registered: Apr-06
|
| Posted on Tuesday, July 04, 2006 - 02:50 pm: |
|
Wiring color codes - 2006 Honda Accord EX
Happy July 4th!!!
I am looking for help like most of the other users here.
I received info about the wiring codes about 2 months ago, and just getting to my project. I pulled the speakers and replaced, but the colors are different then what was posted. Does anybody have the color codes for the speakers in a 06' Honda Accord EX.
The back speaker wires are:
right rear: Blue/yellow and pink
left rear: Blue/Black and Blue white
Here is what I already have - which in not correct.
Posted by xxxxxxxxx on Tuesday, April 25, 2006 - 05:19 pm:
Constant 12V+ White/Green
Switched 12V+ White/Red
Ground Black
Front Speakers
Left Front (+) Blue/Green
Left Front (-) Gray/Black
Right Front (+) Red/Green
Right Front (-) Brown/Black
Rear Speakers
Left Rear (+) Blue/Yellow
Left Rear (-) Gray/White
Right Rear (+) Red/Yellow
Right Rear (-) Brown/White
Thanks in advance for your help. |
New member Username: Bradzbrad
Abbotsford,
B.c
Canada
Post Number: 4
Registered: Jun-06
|
| Posted on Friday, July 14, 2006 - 01:51 am: |
|
Hi, i need wiring harness color code help for a 98 Olds Achieva that came factory with an Am/Fm, cd, cassette head unit. Thanks for any help. |
Gold Member Username: Tjmutlow
Post Number: 2620
Registered: Sep-05
|
| Posted on Friday, July 14, 2006 - 07:05 am: |
|
1998 Oldsmobile Achieva Stereo Information
Constant 12V+ Orange
Switched 12V+ Yellow
Ground Black
Illumination Gray
Dimmer Brown
Antenna Right Front
Front Speakers 4" x 6" Doors
Left Front (+) Tan
Left Front (-) Gray
Right Front (+) Light Green
Right Front (-) Dark Green
Rear Speakers 6" x 9" Rear Deck
Left Rear (+) Brown
Left Rear (-) Yellow
Right Rear (+) Dark Blue
Right Rear (-) Light Blue
• Alarm Information • Cruise Information |
New member Username: Danfoe
Post Number: 1
Registered: Jul-06
|
| Posted on Friday, July 14, 2006 - 02:40 pm: |
|
Need wiring harness color codes for a 2000 Mazda B3000 pickup - can anyone assist ? |
Gold Member Username: Tjmutlow
Post Number: 2627
Registered: Sep-05
|
| Posted on Friday, July 14, 2006 - 03:53 pm: |
|
2000 Mazda B-Series Stereo Information
Constant 12V+ Light Green
Switched 12V+ Yellow/Black
Ground Black
Illumination Light Blue/Red
Dimmer n/a
Amplifier Remote Blue
Antenna Right Front
Front Speakers 6" x 8" Doors
Left Front (+) Orange/Light Green
Left Front (-) Light Blue/White
Right Front (+) Dark Green/Orange
Right Front (-) White/Light Green
Rear Speakers 6" x 8" Rear Corners
Left Rear (+) Gray/Light Blue
Left Rear (-) Tan/Yellow
Right Rear (+) Orange/Red
Right Rear (-) Brown/Pink |
New member Username: WØndf
Post Number: 1
Registered: Jul-06
|
| Posted on Friday, July 14, 2006 - 04:56 pm: |
|
Why dont we skip the middle men eh?
the site they are getting they're information from this site
http://www.the12volt.com
Right in the middle it asks for your car information. Yes you have to register but its free. It will just save space on the threads if y'all go and get the information yourselves. |
New member Username: Ruppe89
GA,
GA
USA
Post Number: 3
Registered: Jul-06
|
| Posted on Friday, July 14, 2006 - 10:53 pm: |
|
I need a wiring Diagram for a 1993 Honda Civic please. E-mail me or send it on here Ruppe89@yahoo.com please. |
New member Username: Nitrorider666
Eureka,
Il
U.S
Post Number: 1
Registered: Jul-06
|
| Posted on Sunday, July 16, 2006 - 02:42 am: |
|
I need the wiring color codes for a 91 Mitsubishi Eclipse my gaiges short out when i rub two wires to gether and they only stay on when two wires are connected. |
New member Username: Rodak
Post Number: 4
Registered: Jul-06
|
| Posted on Sunday, July 16, 2006 - 09:53 am: |
|
Thanks,Newton,for that link. That explains why my two requests for pinout (not color code) info have gone unanswered.
But now I'm wondering why Ty bothers to go get this info over and over again, rather than just posting the link in a prominent place. Personally, I'd rather teach a man to fish than catch a fish for every man who asks. |
New member Username: Yfzfofitty
Post Number: 1
Registered: Jul-06
|
| Posted on Monday, July 17, 2006 - 04:20 pm: |
|
hey i am new but i was wondering if anyone can tell me the color codes to a 1995 ford explorer xlt |
New member Username: Fartacus08
Post Number: 1
Registered: Jul-06
|
| Posted on Monday, July 17, 2006 - 07:02 pm: |
|
i need wire colors for a 1996 ford contour |
New member Username: Mark86234
Post Number: 1
Registered: Jul-06
|
| Posted on Monday, July 31, 2006 - 09:44 pm: |
|
i need 2001 dodge durando stereo wiring harness color code1!!!!!!!!!!!! please help
post or email plzz
mark8623@gmail.com |
New member Username: Jucox
Post Number: 3
Registered: Jul-06
|
| Posted on Tuesday, August 01, 2006 - 12:37 pm: |
|
I need the wiring diagram for a 1995 Isuzu Rodeo - can anyone help? |
New member Username: Decode69
Seoul
Post Number: 1
Registered: Aug-06
|
| Posted on Tuesday, August 01, 2006 - 05:43 pm: |
|
i need Eclipse5303 functions of terminals. becouse i lost male harness..and cant find old style of Eclipse male harness.
i know color codes alredy. but need which wire gose to where. details on connection point.
please ~!! |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 454
Registered: Jan-06
|
| Posted on Tuesday, August 01, 2006 - 06:26 pm: |
|
for Isuzu rodeo LS 95
|
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 458
Registered: Jan-06
|
| Posted on Tuesday, August 01, 2006 - 07:11 pm: |
|
1996 ford contour
|
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 459
Registered: Jan-06
|
| Posted on Tuesday, August 01, 2006 - 07:20 pm: |
|
2001 dodge durando w/amp |
New member Username: Trapdoorwpg
Calgary,
Alberta
Canada
Post Number: 4
Registered: Jul-06
|
| Posted on Tuesday, August 01, 2006 - 09:02 pm: |
|
I'm doing an after market stereo install on a 2006 Dodge Dakota and I
was wondering if anyone would know or have the wire color codes, which I dont think anyone has yet but would be appreciated if you have this
info, thanks a Million ! |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 465
Registered: Jan-06
|
| Posted on Tuesday, August 01, 2006 - 09:44 pm: |
|
I have only for 2005 Dodge Dakota,base radio.
|
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 466
Registered: Jan-06
|
| Posted on Tuesday, August 01, 2006 - 09:44 pm: |
|
I have only for 2005 Dodge Dakota,base radio.
|
New member Username: Decode69
Seoul
Post Number: 2
Registered: Aug-06
|
| Posted on Wednesday, August 02, 2006 - 12:18 am: |
|
i need Eclipse5303 functions of terminals. becouse i lost male harness..and cant find old style of Eclipse male harness.
i know color codes alredy. but need which wire gose to where. details on connection point.
please ~!! |
New member Username: 1sikgsx
WOODLAND PARK,
COLORADO
United States
Post Number: 1
Registered: Aug-06
|
| Posted on Monday, August 07, 2006 - 02:00 am: |
|
Please!!! Need help with 94 olds bravada radio wiring. im trying to install an Alpine cdm-7871 works fine in my other car but wont turn on in bravada. stock radio memory wire has no power. Haynes manual says orange mem. wire goes to fuse block, but when i try to find it with a continuity test can't find it. |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 493
Registered: Jan-06
|
| Posted on Monday, August 07, 2006 - 09:58 am: |
|
Chris,I checked,nothing special!you can do it. |
New member Username: Xxmasakraxx
Post Number: 1
Registered: Aug-06
|
| Posted on Monday, August 07, 2006 - 10:33 am: |
|
Can you help me get color codes for at 1992 Totoya Corolla? |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 494
Registered: Jan-06
|
| Posted on Monday, August 07, 2006 - 11:17 am: |
|
ok...
|
New member Username: Xxmasakraxx
Post Number: 4
Registered: Aug-06
|
| Posted on Monday, August 07, 2006 - 11:37 am: |
|
thanx for ur help |
New member Username: Xxmasakraxx
Post Number: 5
Registered: Aug-06
|
| Posted on Monday, August 07, 2006 - 11:40 am: |
|
would u be able to write it out to which color wire is for what. |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 495
Registered: Jan-06
|
| Posted on Monday, August 07, 2006 - 12:07 pm: |
|
on a speakers wire: where is 1 it (+) plus
and where is 2 it (-) minus
gray it + 12V
blu/yel it memory (+)
brn it grond (-)
that is all.
Good Luck! |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 496
Registered: Jan-06
|
| Posted on Monday, August 07, 2006 - 12:09 pm: |
|
my bad:
grond...read GROUND (-). |
New member Username: Thechipper
Mesa,
Az
Post Number: 1
Registered: Aug-06
|
| Posted on Monday, August 07, 2006 - 02:13 pm: |
|
i need help installing a cd player in my 1988 honda, i have never done this before and i need as much help as possible, can anyone help? |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 497
Registered: Jan-06
|
| Posted on Tuesday, August 08, 2006 - 10:19 am: |
|
what honda you got? accord,civic...EX,DX,LX...et.. |
Bronze Member Username: Th3pwn3r
Chicago,
Illinois
U.S.A
Post Number: 53
Registered: Jul-06
|
| Posted on Tuesday, August 08, 2006 - 12:11 pm: |
|
Can't anybody here use a test light and a little thinking? |
New member Username: Gunnyt
Post Number: 2
Registered: Aug-06
|
| Posted on Tuesday, August 22, 2006 - 08:35 pm: |
|
I am looking for the speaker wire color code for a 2001 Pt Crusier, 6 speaker configuration. I would greatly appericate it! Thanks for the help! |
New member Username: Videomagicman
Post Number: 1
Registered: Aug-06
|
| Posted on Friday, August 25, 2006 - 04:58 am: |
|
Please help i need a wiring schematic/color code for
a FORD VAN E250 econoline 1999. my stereo was stolen and they cut off the factory plug. thanks so much, Rich  |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 580
Registered: Jan-06
|
| Posted on Friday, August 25, 2006 - 07:18 am: |
|
For ford E250 econoline 1999:
|
New member Username: Videomagicman
Post Number: 2
Registered: Aug-06
|
| Posted on Saturday, August 26, 2006 - 07:36 am: |
|
Thanks so much Mike for your help!! I greatly appreciate it! |
Bronze Member Username: Icexx99
Post Number: 17
Registered: Jun-06
|
| Posted on Saturday, August 26, 2006 - 08:50 am: |
|
99 mustang v6 convertible vss wire color and location, and rear signal output wire color and location for hookin up avic n2 |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 585
Registered: Jan-06
|
| Posted on Saturday, August 26, 2006 - 11:13 am: |
|
Chris,rear signal output wire,do you meaned: back up lamp or reversing? if yes, this the schema,the wires what you need it,I highlighted for you in pink color..
|
New member Username: Croneal1986
Laurinburg,
NC
Post Number: 2
Registered: Aug-06
|
| Posted on Sunday, August 27, 2006 - 03:24 pm: |
|
mike,
the wiring diagram you gave me matches color for color and my manufacturer and cd player doesnt. for instance i have a yellow wire and a red wire coming from my cd player the diagram doesnt tell me what to plug in there. |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 148
Registered: Jul-06
|
| Posted on Sunday, August 27, 2006 - 03:38 pm: |
|
Colby,the harness from your CD player will never match to the Car harness.
Look what you have to do!
Read the schema from Mike and read from your CD player,Just by comparing for example,where is Left Rear speaker Plus and Minus and what color they are.I meaned wires.
By the way,Red is always BATTERY. and Yellow is Acc aka Memory or IGNITION WIRE.
But Listen DO NOT CONNECT YOUR NEW HEAD UNIT ONLY BY MATCHING WIRE COLOR,THINK ,THEY WILL NOT FIT LIKE THAT |
New member Username: Othersn555
Post Number: 1
Registered: Sep-06
|
| Posted on Wednesday, September 06, 2006 - 09:37 pm: |
|
Can someone please send me the link to the wiring for a 1998 Contour. Thanks in advance |
Silver Member Username: Delsole
Post Number: 817
Registered: Feb-05
|
| Posted on Wednesday, September 06, 2006 - 09:57 pm: |
|
i need wirering info for my 2005 Ferrari F430 f1
thanks in advance |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 230
Registered: Jul-06
|
| Posted on Wednesday, September 06, 2006 - 11:18 pm: |
|
give me a VIN number and serial number from the driver door!
the original hu Nakamichi? or sound of Palermo? |
Silver Member Username: Delsole
Post Number: 828
Registered: Feb-05
|
| Posted on Thursday, September 07, 2006 - 02:57 pm: |
|
ZFFEW58A350140664
here ya go babe |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 242
Registered: Jul-06
|
| Posted on Thursday, September 07, 2006 - 04:47 pm: |
|
Year: 2005 Make: Ferrari
Model: VIN: ZFFEW58A350140664
Stock Number: Mileage: 3,500
Transmission: Automatic Engine: 8 - Cyl. 4.3 L
Exterior Color: Yellow Interior Color: Black
Body Style: 2DR Title Status: Clear
Current bid: US $279,950.00
Nice Coche you got! BTW,I just was talking to somebody...it was you?
Euro Motorsport
EURO MOTOR SPORT
3868 SW 30th Ave,Marina Mile
Fort Lauderdale, FL 33312
Phone: (954)587-3302
Fax: 954-585-8715
Email: gm7@bellsouth.net
So why you for sell this diablo...do you need money?to pay off your mobile home??? |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 243
Registered: Jul-06
|
| Posted on Thursday, September 07, 2006 - 05:00 pm: |
|
Ok baby...check out your fax...I sended the radio schema...good luck! |
Silver Member Username: Delsole
Post Number: 831
Registered: Feb-05
|
| Posted on Thursday, September 07, 2006 - 05:10 pm: |
|
hahaha
your good,
i just picked the vin off an ebay car never expected for you to drill me. i was joking from the beginnin cuz i wanted to see if anyone could find the wiring info, i wish i had a car like that. haha
your very smart you should be proud of yourself. |
Silver Member Username: Delsole
Post Number: 832
Registered: Feb-05
|
| Posted on Thursday, September 07, 2006 - 05:12 pm: |
|
im very sorry, i cant believe u went through all this trouble. nobody else would have. hope your not madd |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 245
Registered: Jul-06
|
| Posted on Thursday, September 07, 2006 - 06:12 pm: |
|
no Joseph,I am never madd...!you good! |
New member Username: Yahoogirlz
Post Number: 5
Registered: Sep-06
|
| Posted on Friday, September 08, 2006 - 03:45 pm: |
|
greetings
i've got a 90 hyundai ex(hell)cel and i've got the cd hooked up no problem. but i need a constant besides my car battery. new cd anti theft old car NOT
if u have anysuggestions i could really use some help.. |
Silver Member Username: Jenifer_contreras
Tampa,
Florida
USA
Post Number: 251
Registered: Jul-06
|
| Posted on Friday, September 08, 2006 - 06:43 pm: |
|
wass up sld...next time call your self lsd...sounds better,you know this stuff,dont you...
OK Yahoogirlzzz,Any idea what system was before...premium or base(cuz this is very important!)
If the system is BASE then a constant wire is BROWN
if the system is PREMIUM then it RED wire.
check by this schemas (you can compare your plug what is coming to the radio)
go to radio store and get elec.tester,one end to the ground(black) and the other end(red) to any power wire...do not start the car,leave the key in the pocket,try red wire,then brown one...find which one is hot(got +12V and up,can be up 14V).this is will be constant.
for ground use only unpainted metal surf.
|
New member Username: Yahoogirlz
Post Number: 6
Registered: Sep-06
|
| Posted on Friday, September 08, 2006 - 08:00 pm: |
|
u the bomb girl truly appreciate it. i'm getting my voltmeter back tomorrow-so hopefully that will be the end.woohoo
peace
LSD..................what i'll need if i can't get it
2 work |
Silver Member Username: Kaerfpl
Spencerport,
NY
USA
Post Number: 390
Registered: Jun-06
|
| Posted on Friday, September 08, 2006 - 08:37 pm: |
|
Hey, I need help finding wiring codes for a 1993 Olds Cutlass Ciera. |
New member Username: Sirkermit
Colorado Springs,
Colorado
Post Number: 1
Registered: Sep-06
|
| Posted on Monday, September 18, 2006 - 02:02 pm: |
|
Hi there, new to this, saw a lot of great help here. I'm looking for a wiring diagram for a 99 Dodge Neon. If there's any link or any sort of post that could help I would greatly appreciate it. |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 633
Registered: Jan-06
|
| Posted on Monday, September 18, 2006 - 10:53 pm: |
|
ok Robert, take it
|
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 635
Registered: Jan-06
|
| Posted on Monday, September 18, 2006 - 10:54 pm: |
|
ok Robert, take it
|
New member Username: Nsan1t
Post Number: 1
Registered: Sep-06
|
| Posted on Monday, September 18, 2006 - 11:18 pm: |
|
need radio diagram for a 2000 Mazda Protege, nothing has matched my wire colors...
the12volt.com has a diagram but its totally different??? |
New member Username: Nsan1t
Post Number: 2
Registered: Sep-06
|
| Posted on Monday, September 18, 2006 - 11:44 pm: |
|
it has 2 connectores. first has
orange/black
blue/purple
black/red or black/purple
black/white
white
light green/black
red
yellow
second has
green
green/purple
brown
brown/purple |
New member Username: Sirkermit
Colorado Springs,
Colorado
Post Number: 2
Registered: Sep-06
|
| Posted on Tuesday, September 19, 2006 - 01:20 am: |
|
Thanks Mike I greatly appreciate it! |
New member Username: Nsan1t
Post Number: 3
Registered: Sep-06
|
| Posted on Tuesday, September 19, 2006 - 09:11 am: |
|
git it figured out |
New member Username: Nsan1t
Post Number: 4
Registered: Sep-06
|
| Posted on Tuesday, September 19, 2006 - 09:11 am: |
|
got it figured out |
New member Username: Koondawg06
Post Number: 2
Registered: Sep-06
|
| Posted on Tuesday, September 19, 2006 - 04:20 pm: |
|
Sorry all, I just registered and didn't know there was a thread just for wiring.... it'd be great if someone could tell me the wiring for a 2005 Pontiac Sunfire, thanks! |
Silver Member Username: Noviceinstaller
Here,
There
Post Number: 108
Registered: Sep-06
|
| Posted on Tuesday, September 19, 2006 - 04:49 pm: |
|
http://installdr.com/Harnesses/GM-Wiring.pdf
this is the schem for "90+"
but im not sure how far "+" |
Silver Member Username: Noviceinstaller
Here,
There
Post Number: 109
Registered: Sep-06
|
| Posted on Tuesday, September 19, 2006 - 04:52 pm: |
|
my friend has a 2004 pon bonnie ssei and the harness adapter for it is like 40 dollars and u have 2 run it 2 the trunk so he has all his stuff hooked ^ 2 his stock deck..
u cant get the adapt. from like wal;mart, we found it @ a frend of minz stereo store. |
New member Username: Koondawg06
Post Number: 3
Registered: Sep-06
|
| Posted on Wednesday, September 20, 2006 - 03:23 pm: |
|
That didn't seem to work... on the diagram it shows there being two yellow wires coming from the old version, however there is not. There also weren't a few other wires that were used. Any other ideas? |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 650
Registered: Jan-06
|
| Posted on Thursday, September 21, 2006 - 08:56 am: |
|
Dustin,how many wires you got and what the color they are? |
New member Username: Koondawg06
Post Number: 4
Registered: Sep-06
|
| Posted on Friday, September 22, 2006 - 12:07 pm: |
|
okay, coming from my factory wires there are 13 wires.
The colors are:
Black
Dark Blue
Light Blue
Dark Grey
Ran
Light Gray
Light Brown
Light Green
Dark Green
White
Dark Brown
Black (yes, there are two black wires, one being smaller than the other)
Red
I am trying to hook up my aftermarket head unit. It is a Pioneer deh-p 470MP, there are 12 wires. They are:
Black
Purple
Purple w/ black stripe
White
white w/ black stripe
grey
grey w/ black stripe
green
green w/ black stripe
yellow
blue w/ white stripe
red
Any help would be greatly appreciated.. Thanks! |
New member Username: Koondawg06
Post Number: 5
Registered: Sep-06
|
| Posted on Friday, September 22, 2006 - 12:07 pm: |
|
okay, coming from my factory wires there are 13 wires.
The colors are:
Black
Dark Blue
Light Blue
Dark Grey
Tan
Light Gray
Light Brown
Light Green
Dark Green
White
Dark Brown
Black (yes, there are two black wires, one being smaller than the other)
Red
I am trying to hook up my aftermarket head unit. It is a Pioneer deh-p 470MP, there are 12 wires. They are:
Black
Purple
Purple w/ black stripe
White
white w/ black stripe
grey
grey w/ black stripe
green
green w/ black stripe
yellow
blue w/ white stripe
red
Any help would be greatly appreciated.. Thanks! |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 651
Registered: Jan-06
|
| Posted on Friday, September 22, 2006 - 12:37 pm: |
|
Dustin,check this out:
then let me know which one is yours( the base,or U85 or UQ3)...so I can give it to you the right one in full! |
New member Username: Koondawg06
Post Number: 6
Registered: Sep-06
|
| Posted on Friday, September 22, 2006 - 01:26 pm: |
|
How do I know which one mine is? |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 652
Registered: Jan-06
|
| Posted on Friday, September 22, 2006 - 02:33 pm: |
|
just compare all the wires...! |
New member Username: Koondawg06
Post Number: 7
Registered: Sep-06
|
| Posted on Friday, September 22, 2006 - 03:11 pm: |
|
I guess I am just a little confused... The diagrams all show several purple wires. Am I only to be concerned with the middle group of wires? If so, I believe U85 is my set up, because my wiring only has one purple wire, it has 2 blacks, and two greys. So I need the U85 correct? How do I know what to hook to my CD player though? no diagram is in the owners manual, and cannot find one on the internet. Thanks a bunch Mike, I really appreciate the help! |
New member Username: Koondawg06
Post Number: 8
Registered: Sep-06
|
| Posted on Friday, September 22, 2006 - 04:00 pm: |
|
Okay, I found a wiring table for a pioneer cd player... http://www.carstereo.com/help/radio_wires.cfm
My only question is, the wiring diagram coming out of my car only show one wire being used for the battery, it is Orange and it is labeled "battery" So, since the table for the pioneer shows one being for memory, and the other for igntion,
Memory (+12v Constant) Yellow
Ignition (+12v Switched) Red
Which one is do I hook to my orange wire? |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 665
Registered: Jan-06
|
| Posted on Friday, September 22, 2006 - 04:20 pm: |
|
ok,now you will be more confuse...coze it's sucks and "ambush" system! |
New member Username: Koondawg06
Post Number: 9
Registered: Sep-06
|
| Posted on Friday, September 22, 2006 - 04:35 pm: |
|
lol... what you just gave me goes into more detail and clear to the spearkers right? So do you know what I hook to my orange wire from my pioneer? |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 666
Registered: Jan-06
|
| Posted on Friday, September 22, 2006 - 07:49 pm: |
|
From pioneer: Memory wire connects to Orange wire! And Ignition (+12v Switched) Red run straight from the battery (don't forget to put the fuse in line, make it very close to the battery)! |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 667
Registered: Jan-06
|
| Posted on Saturday, September 23, 2006 - 01:32 am: |
|
Dustin! I'm wrong about Ignition (+12v Switched) Red wire. You have to connect straight to ignition lock,the ACC or RUN wire is brown color.
sorry, my bad!!!
 |
New member Username: Koondawg06
Post Number: 10
Registered: Sep-06
|
| Posted on Sunday, September 24, 2006 - 06:58 pm: |
|
Mike,
The brown wire goes to the Left Rear speaker. I got the head unit working, but it's not working properly. It runs all the time, unless you manually turn it off, and for some reason, when I turn on my lights with the cd player on it dims the guage lights (speedometer, etc.) to where you almost can't see the guages. Once I turn the car off, the lights return to their normality, but the cd player quits producing sound. The head unit still works and appears as though it is playing music, but no sound is coming out. So i have to turn my cd player off, then back on and it plays sound, and the lights go dim again. Also, now my car starts to get hot when I'm idling for a period of time. I'm pretty sure this is an indication I messed up somewhere! haha. What I did, is hooked BOTH my red, and yellow wires to my orange wire, because I tested each wire and the orange wire is the only hot wire coming from my car. Also, coming from my car are two ground wires, which confused me so I just wire-nutted one by itself. I am thinking about combining it with the other two. Any suggestions? |
Bronze Member Username: Koondawg06
Post Number: 11
Registered: Sep-06
|
| Posted on Sunday, September 24, 2006 - 08:18 pm: |
|
Well, I now know that you HAVE to have both the red and yellow wires hooked up... but I don't think its good for them to be hooked to the same wire. But I don't know what to do, because the orange wire is the only wire that is hot. Also, attaching both grounds didn't help anything... gahhhh... |
Silver Member Username: Leew
Ketchikan,
ALASKA
USA
Post Number: 668
Registered: Jan-06
|
| Posted on Monday, September 25, 2006 - 10:56 am: |
|
Dustin,you have to connect Memory Wire to Orange OEM wire.For the(+12v Switched) Red wire,you have to run a new line,or from ignition lock(remove the trim panel,and look for the brown wire,it's ACC wire.),or run from cigarette lighter(try the orange wire,it's seems like ACC "+").
Ground "-", you can connect straight to the body(unpainted metal sur..).
About speakers: as I see,there is OEM AMP...that is why you got problem with sound!well,it very simple to kill this problem,buy a 100' of 10-14G wire (15-25$) and rewire all speakers straight to HU.(better, if you get a nice set of speakers too...).
That is all.
Good Luck. |
Bronze Member Username: Koondawg06
Post Number: 12
Registered: Sep-06
|
| Posted on Tuesday, September 26, 2006 - 06:57 pm: |
|
Mike, I just wanted to take a minute to thank you for all the hard work you have been doing to help me out. I really do appreciate it! Where would be the best place to connect this new wire, directly to the switch, or is there a terminal block somewhere I attach it to? I thought of hooking it to my cigarette lighter, but I know my cigarette lighter works at all times, regardless of whether the ignition is on or not, so it would have a permamently hot wire. You're going to kill me for this, but I finally figured out the solution to my speakers not working when i shut my car off, and my guages being dim. When i was originally wiring my HU, I saw that there were two grey wires, identical in color. Well, I saw that one of my grey wires was a speaker wire for my FL speaker, so I chose the closest grey wire to my brown (positive) wire, and wired it up. Well I noticed later on, (after i had forgot what i had done, thinking i did it right) one of my speakers weren't working, so I just assumed I blew it. Well it finally hit me like a ton of bricks that I had my grey wires switched! Coincidentally, the other grey wire is the illumination wire, which was causing my guages to go dim! Now everything works fine, except for the fact that my cd player stays on at all times (unless i manually turn it off) since both my constant and memory are hooked to the same wire. |
New member Username: Aaron06
Post Number: 1
Registered: Oct-06
|
| Posted on Sunday, October 01, 2006 - 02:22 pm: |
|
Anyone have the wiring shematic/color codes for a 1999 ford expedition (eddie bauer). thanks |
New member Username: Aaron06
Post Number: 2
Registered: Oct-06
|
| Posted on Sunday, October 01, 2006 - 02:23 pm: |
|
Anyone have the stereo wiring shematic/color codes for a 1999 ford expedition (eddie bauer). thanks |
New member Username: Thefox_45
Post Number: 2
Registered: Oct-06
|
| Posted on Monday, October 02, 2006 - 10:23 pm: |
|
trying to figure out a after market audiovox rampage model ACD-24 wiring diagram for a 1988 dodge dakota.. it has a 3 way hook-up harness and no sound coumes out but everything else works.. need help.. if anyone can |
New member Username: Toolsaw
Mercerville,
NJ
08619
Post Number: 2
Registered: Oct-06
|
| Posted on Wednesday, October 04, 2006 - 05:43 pm: |
|
pls may I get color codes for 1999 mazda 626 |
New member Username: Zac_stashko
Post Number: 1
Registered: Oct-06
|
| Posted on Thursday, October 05, 2006 - 04:56 pm: |
|
I am trying to hook up my panasonic cd deck into my 1989 Ford Taurus, I was wondering what I needed in the lines of wiring harnesses, mounting kits and if i needed an antenna plug to hook up my deck. Right now I have the factory deck in there and its the original that came with the car. Also if there are any wiring schematics the help would be appreciated. |
New member Username: Will_23
Post Number: 2
Registered: Oct-06
|
| Posted on Sunday, October 08, 2006 - 01:35 am: |
|
hi
i need a wiring diagram for a 1992 mazda ms8-efini |
New member Username: Teddy456
Chandler,
Arizona
United States
Post Number: 1
Registered: Oct-06
|
| Posted on Monday, October 16, 2006 - 09:13 pm: |
|
Need colors for 2001 chevy S10 truck please help out thank you going from stock to kenwood |
New member Username: Dustin_k
Post Number: 2
Registered: Oct-06
|
| Posted on Monday, October 23, 2006 - 09:50 pm: |
|
i need help hooking up a cd player to an 88 ford escort, i don't know which wire goes with which wire, because their different colors...any help???? |
New member Username: Am_dew
Post Number: 1
Registered: Oct-06
|
| Posted on Tuesday, October 24, 2006 - 11:01 am: |
|
I've got a 2005 Ford Explorer XLT with factory AM/FM, single CD system, with factory sub.
I am thinking of replacing the factory HU.
Does anyone know for certain if this factory system has an external factory amp which drives the four 5x7/6x8 door speakers? If so, replacing the HU is going to involve more work than I anticipated since I will neeed to either run new speaker wires from the HU to the speakers or tap into the existing ones somewhere after the factory amp.
Thanks! |
New member Username: M_a_a_randall
Post Number: 1
Registered: Dec-06
|
| Posted on Monday, December 04, 2006 - 09:42 pm: |
|
Hi, ive got a 2003 Ford Zx2 with a ford head unit number 3S4K-18C838-AA and Cant find a wiring diagram for it to find out which colors are wich wires, can any one help? |
Gold Member Username: Leew
XXXX!!WWWW,
Yokosuka, ...
SPESNAZ. ...
Post Number: 1054
Registered: Jan-06
|
| Posted on Monday, December 04, 2006 - 10:29 pm: |
|
you can have it here! Click me, I am a lift!  |
Upload
